• THE EMINENCE WHEELHOUSE 150 IS A 12" GUITAR SPEAKER THAT HANDLES 150 WATS RMS
• FEATURES A HEMP CONE FOR A WARM SOUND, LIGHTWEIGHT NEODYMIUM MAGNET & HIGH SENSITIVITY OF 101.4DB SPL
• DESIGNED TO GIVE YOU SMOOTH WARM TONE THROUGH ITS' ENTIRE FREQUENCY RANGE
• WORKS WELL FOR COUNTRY, FUSION & BLUES
• WELL SUITED FOR APPLICATIONS IN OPEN OR CLOSED BACK CABINETS
• MADE BY HAND IN THE USA
• AVAILABLE IN 8 OHMS ONLY

THIS EMINENCE WHEELOUSESE 150 IS A 12 INCH GUITAR SPEAKER DELIVERS A WARM SMOOTH SOUND & HANDLES 150 WATTS RMS!
Free UPS Ground Shipping in the U.S.	WHEELHOUSE 150  -  8 ohms No Longer Available
SPEAKER MODEL	WHEELHOUSE 150
SPECIFICATIONS
Nominal Basket Diameter	12" / 305mm
Impedance	8 ohms
RMS Power Rating	150 Watts
Usable Frequency Response	80Hz-3.8kHz
Voice Coil Diameter	2.5" / 63mm
Sensitivity (1W/1m)	101.4dB
Magnet Weight	11 oz.
MOUNTING INFORMATION
Overall Diameter	12.17" / 309.1mm
Bolt Circle Diameter	11.75" / 298.5mm
Baffle Cutout Diameter	11.13" / 282.7mm
No. Of Mounting Holes	8
Mounting Hole Diameter	0.24" / 6.1mm
Overall Depth	6.25" / 158.8mm
Net Weight	6.6lbs. / 3.0 kg.
Shipping Weight	8.7lbs. / 3.95 kg.
MATERIALS
Basket	Pressed Steel
Voice Coil	Edgewound Aluminum
Coil Former Material	Polyimide
Dust Cap	Treated Paper
Cone	Hemp
Core Details	Vented
Surround	Paper
Magnet	Neodymium
THIELE-SMALL PARAMETERS
Resonant Frequency (fs)	82 Hz
Impedance (Re)	7.46 ohms
Coil Inductance (Le)	0.43mH
Electromagnetic Q (Qes)	0.44
Mechanical Q (Qms)	14.28
Total Q (Qts)	.43
Compliance Equiv. Vol. (Vas)	47.22 Liters / 1.67 cu. ft.
BL Product (BL)	16.31 T-M
Voice Coil Overhang (Xmax)	2.22mm
Diaphragm Mass (Mms)	30 Grams
Surface Area of Cone (Sd)	.05324m2
FREQUENCY RESPONSE GRAPH
