ASHLY |
GQX-3102 PROFESSIONAL EQUALIZER |
QUALITY DUAL 31 BAND GRAPHIC EQ WORKS GREAT FOR LIVE SOUND! |
Discontinued |
ASHLY
MODEL |
GQX-3102 |
FILTERS |
|
Type |
Constant Q Wein-Bridge |
Number | 2x31 |
Bandwidth | 1/3 Octave |
Tolerance | +/-3% |
Range | +/-15dB |
Subsonic | 12dB/Octave @ 40Hz |
SPECIFICATIONS |
|
Input Type | Active Balanced |
Input Impedance |
20k ohm |
Input
Max. Level |
+22dBu |
Output
Type
|
Servo-balanced |
Output Min. Load Impedance | 600 ohms |
Output Max. Level | +22dBu |
Frequency |
+/-25dB 20Hz-20kHz |
IM Distortion (SMPTE) |
<.01% @+20dBu |
Total Harmonic Distortion |
<.01% @+20dBu, 20Hz-20kHz |
Equivalent Input Noise |
-96dBu |
Connectors |
XLR, 1/4" & barrier strip |
Power Requirements | 120VAC, 50-60Hz, 17W |
Shipping Weight | 15 lbs. |
Dimensions | 19"W x 5.25"H x 6"D |
