Radian 10CRF6430-XO Crossovers - Radian 2 way 10CRF6430-XO crossover - Radian 10CRF6430-XO 2-way passive 1.7kHz crossover to be used with the Radian 10CRF6430. The Radian 2-way crossover is rated at 300 watts RMS. Radian passive crossovers here.

RADIAN 10CRF6430-XO - 2-WAY POWERFUL CROSSOVER

THE RADIAN 10CRF6430-XO IS A HIGH QUALITY 2-WAY CROSSOVER W/ A 1.7KHZ CROSSOVER
DESIGNED TO BE USED WITH THE RADIAN 10CRF6430 10" COAXIAL PLANAR RIBBON SPEAKER
LF FREQUENCY W/ A 18DB PER OCTAVE SLOPE & HF FREQUENCY W/ A 12DB PER OCTAVE SLOPE
HANDLES 300 WATTS RMS & 600 WATTS PROGRAM
PREMIUM POLYPROPYLENE CAPACITORS & AIR CORE INDUCTORS
WIRING HARNESS INCLUDED
ALL CONNECTIONS ARE A SIMPLE PLUG & PLAY

THE RADIAN 10CRF6430-XO IS A HIGH QUALITY 2-WAY CROSSOVER!

Radian 10CRF6430-XO

Item Price: $89.95

CROSSOVER MODEL	10CRF6430-XO
Specifications
Type	2-Way
Crossover Frequency	1.8kHz
Impedance (Highs)	8 ohms
Impedance (Lows)	8 ohms
RMS Power Handling	300 Watts
Program Power Handling	600 Watts
Slope - High Frequency	12dB/octave
Slope - Low Frequency	18dB/octave
High Frequency Attenuation	-6.5dB
High Frequency Protection	Polywsitch
Materials
Inductors	Air Core
Capacitors	Polypropylene
Harness Wiring	18 Gauge Copper Stranded Wire
Dimensions
Physical Size	5.9" Length x 4.65" Width x 1.657" Height
Number of Mounting Holes	4
Mounting Hole Diameter	.18"
Net Weight	1.66 lbs.
