PROFESSIONAL POWER AMPLIFIERS
*RAM AUDIO*	*CROWN*

RAM AUDIO & CROWN PROFESSIONAL POWER AMPLIFIERS
RAM AUDIO 'ALL IN ONE' DSP POWER AMP MODULES
VARIETY OF AMPLIFIERS DEPENDING UPON YOUR APPLICATION

ASYM SERIES

AS-2K3

2 Channel
Channel A - 1,500 Watts @ 4 or 8 Ohms & 750 Watts @ 2 Ohms
Channel B - 400 Watts @ 8 Ohms & 750 Watts @ 4 Ohms & 750 Watts @ 2 Ohms
THD - <0.05%
XLR Input, XLR Link, Powercon True 1 In-Out, USB, RJ45, Barrier Strip
Protection - Turn On Transients, Over Heating, DC, RF, Short Circuit, Mismatched Loads, ICL & PMS
External Dimensions - 5.1" Wide x 17.4" Height
Weight - 3.3 lbs. / 1.5 kg.
Made In Spain

Item Price: $1,415.00

AS-1K5

2 Channel
Channel A - 400 Watts @ 8 Ohms & 750 Watts @ 4 Ohms & 750 Watts @ 2 Ohms
Channel B - 400 Watts @ 8 Ohms & 750 Watts @ 4 Ohms & 750 Watts @ 2 Ohms
Bridge Mono - 1,500 Watts @ 4 and 8 Ohms
THD - <0.05%
XLR Input, XLR Link, Powercon True 1 In-Out, USB, RJ45, Barrier Strip
Protection - Turn On Transients, Over Heating, DC, RF, Short Circuit, Mismatched Loads, ICL & PMS
External Dimensions - 5.1" Wide x 17.4" Height
Weight - 3.3 lbs. / 1.5 kg.
Made In Spain

Item Price: $1,342.95

SUB SERIES

PICTURE COMING SOON

SB-3K

2 Channel
Channel A - 400 Watts @ 8 Ohms & 750 Watts @ 4 Ohms & 1,500 Watts @ 2 Ohms
Channel B - 400 Watts @ 8 Ohms & 750 Watts @ 4 Ohms & 1,500 Watts @ 2 Ohms
Bridge Mono - 1,500 Watts @ 8 Ohms
Bridge Mono - 3,000 Watts @ 4 Ohms
THD - <0.05%
XLR Input, XLR Link, Powercon True 1 In-Out, USB, RJ45, Barrier Strip
Protection - Turn On Transients, Over Heating, DC, RF, Short Circuit, Mismatched Loads, ICL & PMS
External Dimensions - 20" Wide x 7" Height
Weight - 5.5 lbs. / 2.5 kg.
Made In Spain

Item Price: $1,646.50

PICTURE COMING SOON

SB6K-Bi

2 Channel
Channel A - 1,500 Watts @ 8 Ohms & 3,000 Watts @ 4 Ohms & 1,500 Watts @ 2 Ohms
Channel B - 1,500 Watts @ 8 Ohms & 3,000 Watts @ 4 Ohms & 1,500 Watts @ 2 Ohms
THD - <0.05%
XLR Input, XLR Link, Powercon True 1 In-Out, USB, RJ45, Barrier Strip
Protection - Turn On Transients, Over Heating, DC, RF, Short Circuit, Mismatched Loads, ICL & PMS
External Dimensions - 19.7" Wide x 13" Height
Weight - 6.82 lbs. / 3.1 kg.
Made In Spain

Item Price: $2,049.00

PICTURE COMING SOON

SB6K-TRi

3 Channel
Channel A - 400 Watts @ 8 Ohms, 750 Watts @ 4 Ohms & 1,500 Watts @ 2 Ohms
Channel B - 400 Watts @ 8 Ohms & 3,000 Watts @ 4 Ohms & 1,500 Watts @ 2 Ohms
Channel C - 1,500 Watts @ 8 Ohms & 3,000 Watts @ 4 Ohms & 1,500 Watts @ 2 Ohms
THD - <0.05%
XLR Input, XLR Link, Powercon True 1 In-Out, USB, RJ45, Barrier Strip
Protection - Turn On Transients, Over Heating, DC, RF, Short Circuit, Mismatched Loads, ICL & PMS
External Dimensions - 19.7" Wide x 13" Height
Weight - 6.82 lbs. / 3.1 kg.
Made In Spain

Item Price: $2,341.95

XTR SERIES - EXTREME POWER RACK AMPLIFIERS

XTR-18K

New "Extreme" XTR-18K High Power Amplifier
2 x 9,000 Watts @ 4 Ohms
2 x 4,500 Watts @ 8 Ohms
Dual PFC QuantaPulse™ Regulated SMPS
RAM Audio Power Management System
High Efficiency, Heavy Duty Audio Power Section For Extreme Use
Efficient Front To Back Cooling
Dedicated Design For Extreme Power Subwoofers Systems
Weighs Only 26.5 lbs.
Runs On A 220 Volt Line Only

Item Price: $6,995.00

Free UPS Ground Shipping in the U.S.

XTR-12K

New "Extreme" XTR-12K High Power Amplifier
2 x 6,000 Watts @ 4 Ohms
2 x 3,000 Watts @ 8 Ohms
Dual PFC QuantaPulse™ Regulated SMPS
RAM Audio Power Management System
High Efficiency, Heavy Duty Audio Power Section For Extreme Use
Efficient Front To Back Cooling
Dedicated Design For Extreme Power Subwoofers Systems
Weighs Only 26.5 lbs.
Runs On A 120 Volt Line

Item Price: $6,495.00

Free UPS Ground Shipping in the U.S.

Ram Audio MDi8-6K

MDi8-6K

Complete Spec Sheet Coming Soon

New High Audio Quality In An Extremely Efficient Class D Design
8 x 750 Watts @ 4 Ohms
8 x 400 Watts @ 8 Ohms
Bridged - 4 x 1,500 Watts @ 8 Ohms
Last Generation PFC QuantaPulse™ Switch Mode PS
70V/100V Line Direct/Drive Output
RAM Audio Power Management System (PMS™) & Clip Limiter (ICL™)
Upside-Down Design To Avoid Fan Dust Accumulation
Detented Sealed Potentiometers
Protections - Soft-Start, Turn-On Turn-Off Transients, Muting At Turn-On, Over-Heating, DC, RF, Short-Circuit, Open or Mismatched Loads, Overloaded Power Supply, ICL™, PMS™ and SSP™.
Weighs Only 16.5 lbs.
Runs On A 120 Volt Line

Item Price: $3,695.00

Free UPS Ground Shipping in the U.S.

PROFESSIONAL AMPLIFIERS

XTI2 SERIES

Crown XTi 2 Series Lightweight Amplifiers
Peak_x Plus™ Limiters provide the ultimate in system performance and protection by allowing full control over threshold, attack, and release
Enhanced Subharmonic Synth section provides user control over frequency, gain and filter type for system-specific tuning
3 User-defined fan mode controls – normal, early and fullspeed – for matching fan performance to a specific application
New system monitoring provides software visibility of AC line voltage and power supply temperature
Integrated cast-aluminum handles for easy handling and enhanced durability
Locking power cord clip provides a secure connection between the amplifier and power cord
Updated HiQnet Band Manager™ and System Architect™ control software
Increased number of presets to a total of 50; 49 of which are user definable

			XTi 1002 - Item Price: $675.00
			XTi 2002 - Item Price: $949.00
			XTi 4002 - Item Price: $1,295.00
			XTi 6002 - Item Price: $2,599.00
	XTi 1002	XTi 2002		XTi 4002	XTi 6002
2Ω Stereo (per ch.)	700W	1000W		1600W	3000W
4Ω Stereo (per ch.)	500W	800W		1200W	2100W
8Ω Stereo (per ch.)	275W	475W		650W	1200W
8Ω Bridge-Mono	1000W	1600W		2400W	4200W
4Ω Bridge-Mono	1400W	2000W		3200W	6000W
INTEGRATED PROCESSING
Input EQ
6 parametric filters per channel with adjustable Q, ±15 dB boost/cut. Also adjustable high and low shelving filters. This 8-filter EQ section can be bypassed
Crossover Filters
Highpass and Lowpass per channel. Butterworth 6/12/18/24 dB per octave. Linkwitz-Riley 24/48 dB per Octave. Also includes ± 15 dB bandpass gain and polarity control
Output EQ
8 parametric filters per channel with adjustable Q, ±15 dB boost/cut. This 8-filter EQ section can be bypassed
Delay
For signal alignment of driver; 50 mS of total delay
SubHarmonic Synth
Takes the low-frequency content of the input signal and "synthesizes" a new signal that is the same as the input signal but one octave lower. The new synthesized signal is then mixed with the original signal to create the effect. Users now have control over frequency, gain, and filter type
Peak_x™ Plus Limiter
User defeatable limiter that allows users to control Threshold, Attack, and Release times
Presets
50 total presets, 49 of which are user-definable
PERFORMANCE
Sensitivity (for full rated power at 4 ohms)			1.4 Vrms
Frequency Response (at 1 watt, 20 Hz - 20 kHz)			+0 dB, –1 dB
Signal-to-Noise Ratio (below rated 1kHz power at 8 ohms)			XTi1002/2002/4002: 100 dB (A weighted) XTi6002: 103 dB (A weighted)
Total Harmonic Distortion (THD)			< 0.5%
Damping Factor 20 Hz to 1 kHz			> 500
Crosstalk (below rated power)			20 kHz - 1 kHz: > 70 db
Input Impedance (nominal)			20k ohms balanced, 10k ohms unbalanced
Maximum Input Signal			+22 dBu typical
AC Line Voltage and Frequency Configurations			100 VAC, 120 VAC, 220-240 VAC 50/60 Hz
AC Line Current (120 VAC amplifier playing 1/8 power pink noise into 4 ohms per ch)			XTi1002: 6.8A; no more than 38W at idle XTi2002: 8.3A; no more than 38W at idle XTi4002: 10.5A; no more than 38W at idle XTi6002: 15.3A; no more than 180W at idle
Operating Temperature			0°C to 40°C at 95% relative humidity (non-condensing)
CONTROLS
Level			Two front-panel rotary level controls, one for each channel
Power Switch			On/Off switch applies AC power to the amplifier
Sel/Prev/Next Buttons			Three buttons near the LCD screen that are used to access menu items and front panel lockout
LCD Screen			Backlit liquid crystal display that shows preset and processing status
INDICATORS
Signal Indicator			Green LED, one per channel, illuminates when a very low-level signal is present at input (may be used for troubleshooting cable runs)
–10 Indicator			Green LED flashes when output signal exceeds -10 dB below clip
–20 Indicator			Green LED flashes when output signal level exceeds -20 dB below clip
Ready Indicator			Green LED, one per channel, illuminates when the amplifier is ready to produce audio
Clip Indicator			Red LED, one per channel, turns on at the threshold of audible distortion
Temp Indicator			Red LED, one per channel, illuminates under excessive temperature conditions
Power Indicator			Blue LED illuminates when the amplifier has been turned on and has power
INPUT/OUTPOT CONNECTORS
Input Connectors			XLR, one per channel
Link/Out Connector			Loop-thru signal from input connector for linking another amplifier, one per channel
Output Connectors			Two Neutrik® Speakon® NL4MP output connectors. Channel-1 Speakon® is wired with Ch. 1 and Ch. 2 outputs for use with optional single 4-conductor cable. Two binding post outputs (in parallel with Speakon® connectors)
HiQnet™ USB Connector			Type B, connects to HiQnet™ network
CONSTRUCTION
Chassis			Steel
Front Panel			Cast-aluminum
Cooling			Proportional speed fan with front-to-rear airflow
Dimensions			XTi 1002/2002/4002: 19" (W) x 3.5" (H) x 12.25" (D) XTi 6002: 19" (W) x 3.5" (H) x 16.2" (D)
Net Weight			XTi 1002/2002/4002: 18.5 lbs (8.4kg) XTi 6002: 24.0 lbs (10.9kg)
Shipping Weight			XTi 1002/2002/4002: 21.5 lbs (9.8kg) XTi 6002: 30.0 lbs (13.6kg)
