Genuine Eminence

APT HIGH POWER SUPERTWEETERS

CIARE

TWEETER

Ciare 1.26Nd TW

• NEW Tweeter
• 3.54" diameter
• Lightweight Neodymium Magnet
• Weighs Only 1.21 lbs.
• 8 ohms
• 20 Watts AES
• 40 Watts Program
• 2.0kHz - 20kHz
• 103dB SPL
• Works well as a tweeter upgrade in bass cabinets, home hifi, etc.
• One of our smoothest sounding tweeters!

Item Price: $138.75

Ciare 1.38 TW

• 5.9" diameter
• 8 ohms
• Powerful 150 Watts AES
• 2.5kHz - 20kHz
• 105dB SPL
• Great for hifi speakers, studio monitors, DJ systems, live sound, etc.

Item Price: $84.95

Ciare CT440

• New High Quality Horn Tweeter
• 4.41" H x 4.41" W
• 8 ohms
• Handles A Powerful 250 Watts AES & 500 Watts Program
• 2.0kHz - 20kHz
• High Efficiency of 110dB SPL
• 1.75" Mylar Voice Coil For A Super Smooth Sound
• Extremely Low Distortion
• Rising Response Up To 20kHz
• Lightweight Neodymium Magnet
• Strong Aluminum Horn
• For The Highest Quality High Frequency Applications

Item Price: $241.50

FD371

• High Frequency Supertweeter
• 8 Ohms
• 35 Watts AES
• 70 Watts Program
• 107dB SPL
• Frequency Range: 2.6kHz to 20kHz
• Minimum Crossover Freq.: 2.6kHz
• Weighs 2.8lbs.
• Ketone Polymer Diaphragm Delivers A Smooth Flat Response
• Machined From A Solid Block Of Aluminum!

Item Price: $192.95

B&C SUPERTWEETERS

DE35

• 1.25" Supertweeter
• 8 Ohms - 108dB SPL
• 25 Watts AES Standard
• 50 Watts Program
• 3.5kHz - 18kHz
• Works Great As A Supertweeter In Bass Guitar Cabinets & PA Speakers!

Item Price: $88.66

HIGH FREQUENCY TWEETERS

CD1S

Beyma CD1S

• New 1" Screw-On Type High Frequency Driver
• 8 Ohms
• 30 Watts Program
• 60 Watts Program
• 106dB SPL
• Warm Top End Up To 20kHz & Good Mids Down to 2.5kHz
• Nice Replacement High Frequency In Bass Guitar Cabinets, PA Cabinets, Etc.
• 8 Ohms

Item Price: $69.95

CP12N

Beyma CP12N

• 1" H.F. Compression Tweeter
• 8 Ohms
• 15 Watts RMS
• 30 Watts Program
• 107dB SPL
• 40° Conical Dispersion
• 1" Aluminum Edgewound Voice Coil
• Aluminum Diaphragm & Nomex Former For A Smooth Response
• Designed For Outdoor Applications, Semi-Pro Systems & High Fidelity Speakers

Item Price: $59.99

CP16

Beyma CP16

• 1" H.F. Compression Tweeter
• 8 Ohms
• 15 Watts RMS
• 30 Watts Program
• 107dB SPL
• 40° Conical Dispersion
• Smooth Detailed Highs
• 1" Aluminum Edgewound Voice Coil
• Aluminum Diaphragm & Nomex Former For A Smooth Response
• Designed For Outdoor Applications, Semi-Pro Systems & High Fidelity Speakers

Item Price: $59.99

CP22FB

Beyma CP22FB

• New 1" H.F. Bullet Tweeter
• Powdered Coated Black Matte Finish
• 8 Ohms
• Improved Power Handling
• 35 Watts RMS
• 70 Watts Program
• 107dB SPL
• 40° Conical Dispersion
• 1.5" Aluminum Edgewound Voice Coil
• Ferro Fluid Cooled
• Extremely smooth sounding
• Awesome Supertweeter In Bass Guitar Cabinets

Item Price: $139.95

CP22MF

Beyma CP22MF

• New 1" H.F. Bullet Tweeter
• 8 Ohms
• Improved Power Handling
• 35 Watts RMS
• 70 Watts Program
• 107dB SPL
• 40° Conical Dispersion
• 1.5" Aluminum Edgewound Voice Coil
• Ferro Fluid Cooled
• Extremely smooth sounding
• Awesome Supertweeter In Bass Guitar Cabinets
• Works Well For Sound Reinforcement & Hi Fidelity Applications

Item Price: $139.95

CP21/F

Beyma CP21/F

• 1" H.F. Slot Tweeter
• 8 Ohms
• 25 Watts RMS
• 50 Watts Program
• 105dB SPL
• 140°H x 40°V Dispersion
• 1.5" Aluminum Edgewound Voice Coil
• Low Distortion!
• For Systems That Need A Wide Horizontal Dispersion
• Designed For Sound Reinforcement & Studio Applications

Item Price: $129.95

CP25

Beyma CP25

• 1" H.F. Horn Tweeter
• 8 Ohms
• 25 Watts RMS
• 50 Watts Program
• 100°H x 60°W Dispersion
• 1.5" Aluminum Edgewound Voice Coil
• 104dB SPL
• Great For Studio Monitors & Hi Fidelity Applications

No Longer Available

TPL-75

Beyma TPL-75

• NEW Pleated Diaphragm Tweeter
• Designed To Be Very Flat From 1.5kHz to 23kHz
• 8 Ohms
• 40 Watts AES above 1.2kHz
• 80 Watts Program above 1.2kHz
• 92dB SPL
• Excellent Choice For The Highest Quality Home Hi-Fi / Studio Monitor Playback Systems
• Nice Bell Like Highs Similar to That Of A Beryllium Diaphragm

Item Price: $319.95

TPL-150

Beyma TPL-150

• Pleated Diaphragm Tweeter
• Flat Black Finish
• 8 Ohms
• 80 Watts AES above 1.0kHz
• 160 Watts Program above 1.0kHz
• 99dB SPL
• Extended Response up to 23kHz
• Nice Bell Like Highs Similar to That Of A Beryllium Diaphragm

Item Price: $519.95

TPL-150/Black

Beyma TPL-150/Black

• New Pleated Diaphragm Tweeter
• Attractive Shiny Smooth Black Finish
• 8 Ohms
• 80 Watts AES above 1.0kHz
• 160 Watts Program above 1.0kHz
• 99dB SPL
• Extended Response up to 23kHz
• Nice Bell Like Highs Similar to That Of A Beryllium Diaphragm

Item Price: $519.95

TPL-150/Silver

Beyma TPL-150/Silver

• New Pleated Diaphragm Tweeter
• Attractive Shiny Smooth Silver Finish
• 8 Ohms
• 80 Watts AES above 1.0kHz
• 160 Watts Program above 1.0kHz
• 99dB SPL
• Extended Response up to 23kHz
• Nice Bell Like Highs Similar to That Of A Beryllium Diaphragm

Item Price: $519.95

TPL-150H

Beyma TPL-150H

• New Pleated Diaphragm Horn Tweeter
• 8 Ohms
• 80 Watts AES above 1.0kHz
• 160 Watts Program above 1.0kHz
• 102dB SPL
• Extended Frequency Range From 700Hz 23kHz
• 80°H x 30°V Dispersion
• Nice Bell Like Highs Similar to That Of A Beryllium Diaphragm

Item Price: $619.95

TPL-200/B

Beyma TPL-200/B

• New Pleated Diaphragm Tweeter
• Attractive Shiny Smooth Black Finish
• 8 Ohms
• 120 Watts AES above 1.0kHz
• 240 Watts Program above 1.0kHz
• High Sensitivity of 101dB SPL
• Extended Frequency Range From 1kHz 23kHz
• 120°H x 20°V Dispersion
• Strong Pronounced Mids With Nice Bell Like Highs Similar to That Of A Beryllium Diaphragm

Item Price: $694.95

TPL-200/S

Beyma TPL-200/S

• New Pleated Diaphragm Tweeter
• Attractive Shiny Smooth Silver Finish
• 8 Ohms
• 120 Watts AES above 1.0kHz
• 240 Watts Program above 1.0kHz
• High Sensitivity of 101dB SPL
• Extended Frequency Range From 1kHz 23kHz
• 120°H x 20°V Dispersion
• Strong Pronounced Mids With Nice Bell Like Highs Similar to That Of A Beryllium Diaphragm

Item Price: $694.95

TPL-200/H

Beyma TPL-200/H

• New Pleated Diaphragm Horn Tweeter
• 8 Ohms
• 120 Watts AES above 1.0kHz
• 240 Watts Program above 1.0kHz
• High Sensitivity of 104dB SPL
• Extended Frequency Range From 1kHz 23kHz
• 80°H x 30°V Dispersion
• Strong Pronounced Mids With Nice Bell Like Highs Similar to That Of A Beryllium Diaphragm

Item Price: $759.95

T2030

Beyma T2030

• 1" Dome Tweeter
• 8 Ohms
• 15 Watts RMS above 2.0kHz
• 30 Watts Program above 2.0kHz
• 95dB SPL
• Aluminum Diaphragm
• Natural Sounding Highs

Item Price: $87.95

HIGH FREQUENCY PLANAR RIBBON DRIVERS

LT6

• New LT6 High Frequency Planar Ribbon Driver
• 40 Watts AES above 1.2kHz
• Wide Frequency Range From 1.7kHz Up To 30kHz
• 99dB SPL
• Super Sonic Transparency & Resolution
• Lightweight Neodymium Magnet Weighs 1.2 lbs.
• Works Well In Line Array Systems, Home Hi-Fi Speakers, Etc.

Radian LT6

Item Price: $136.99

CTS PIEZO TWEETERS, HF DRIVERS & HORNS

PIEZO HIGH FREQUENCY DRIVERS & HORNS

KSN-1142

• Screw-on piezo tweeter/driver
• Powerful 400W RMS
• Originally designed by Motorola
• Powerline Series Has Built-In Breaker Protection
• Frequency Response of 1.8k-30kHz
• Impedance: Appears as a .13 uF capacitor
• Overall Diameter - 2.44"
• Overall Depth - 2.75"
• Sensitivity of 92db SPL
• Standard 1.375" Thread Type
• Don't be fooled by imitations, this is the real deal!

Item Price: $36.95

KSN-1188

• Screw-on piezo tweeter/driver
• Powerful 400W RMS
• Originally designed by Motorola
• Powerline Series Has Built-In Breaker Protection
• Frequency Response of 800Hz-20kHz
• Impedance: Appears as a .13 uF capacitor
• Overall Diameter - 3.75"
• Overall Depth - 3.0"
• Sensitivity of 93db SPL
• Standard 1.375" Thread Type
• Don't be fooled by imitations, this is the real deal!

Item Price: $54.95

PIEZO TWEETERS

KSN-1005

• 3.4" x 3.4" Piezo Tweeter
• 100W RMS power handling
• Originally designed by Motorola
• Frequency Response of 4.0k-27kHz
• Impedance: Appears as a .13 uF capacitor
• Sensitivity of 94db SPL
• O.D. - 3.4"W x 3.4"H x 3.38"D
• Cutout - 3" Diameter
• Bolt Circle Diameter - 4.0"
• Don't be fooled by imitations, this is the real deal!

Item Price: $27.95

KSN-1141

• 3" x 7" Horn tweeter
• Powerful 400W RMS
• Originally designed by Motorola
• Powerline Series Has Built-In Breaker Protection
• Frequency Response of 1.8k-30kHz
• Impedance: Appears as a .3 uF capacitor
• Sensitivity of 92db SPL
• O.D. - 7.35"W x 3.1"H x 4.25"D
• Cutout - 6.25"W x 2.125"H
• Don't be fooled by imitations, this is the real deal!

Item Price: $38.95

KSN-1165

• 4.25" x 4.25" Horn tweeter
• Powerful 400W RMS
• Originally designed by Motorola
• Powerline Series Has Built-In Breaker Protection
• Frequency Response of 1.8k-30kHz
• Impedance: Appears as a .3 uF capacitor
• Sensitivity of 92db SPL
• O.D. - 4.3"W x 4.3"H x 3.5"D
• Cutout - 3.5" Diameter
• Bolt Circle - 5.2" Diameter
• Don't be fooled by imitations, this is the real deal!

Item Price: $38.95

KSN-1177

• 6.3" x 3.75" Twin Bullet Tweeter
• 75W RMS power handling
• Originally designed by Motorola
• Frequency Response of 3.5k-20kHz
• Impedance: Appears as a .3 uF capacitor
• High Sensitivity of 99db SPL
• O.D. - 6.3"W x 3.75"H x 4"D
• Cutout - 4.875"W x 2"H
• Don't be fooled by imitations, this is the real deal!

Item Price: $39.95

PROFESSIONAL COMPONENTS

ULTRA-HIGH FREQUENCYTRANSDUCER

2402H

• 8 ohms

• 40 watts continuous

• 2.5kHz - 15kHz

• 40° conical @ 10 kHz

• 110 dB SPL

No Longer Available

Replacement Beyma CP22MF

2404H

• 8 ohms

• 40 watts continuous

• 3kHz - 21.5kHz

• 100° x 100°

• 105 dB SPL

No Longer Available

Replacement Beyma CP25

2405H

• 8 ohms

• 40 watts above 6kHz

• 6.5kHz - 21.5kHz

• 90° x 25° @ 16kHz

• 105 dB SPL

No Longer Available

Replacement Beyma CP21/F

P.AUDIO

PHT404

• 10.5" x 4.5"
• 30W RMS
• 3-16kHz
• 100° x 60° Conical Dispersion
• 105db
• 8 ohms
• Cast aluminum

PHT High Frequency Drivers

  $55.95

PHT406

• 4.71" round
• 30W RMS
• 2-16kHz
• 50° Conical Dispersion
• 105db
• 8 ohms

No Longer Available

PHT408

• 7.6" x 6.1"
• 30W RMS
• 2-15kHz
• 105db
• 8 ohms

PHT High Frequency Drivers

  $51.95

PHT410

• 4.3" x 4.3"
• 20W RMS
• 2-16kHz
• 80° Conical Dispersion
• 105db
• 8 ohms

PHT High Frequency Drivers

  $51.59
